General Specifications |
Frequency Range
|
|
VHF: 136-174MHz UHF: 400-470MHz, 450-520MHz |
| Number of channels |
|
16 |
Channel spacing |
|
12.5/25.0KHz |
| Operating Voltage |
|
7.4V |
Standard battery |
|
1800mah (lithium ion) |
| Modulation mode |
|
F3E |
Output Power |
|
VHF:6.0W/2.0W UHF:6.0W/2.0W |
| Operating temperature range |
|
-20℃~+60℃ |
Antenna impedance |
|
50Ω |
| Dimensions (H x W x D)(Without antenna) |
|
103 x 53 x 28.5mm |
Weight (including antenna and battery) |
|
235g |
| Sensitivity |
|
≤0.3μV/0.2μV |
Audio output power |
|
500mW |
|
The above specifications are tested in accordance with TIA/EIA-603 standard. The receive part specification applies only to 136-174MHz,
400-470MHz. As the technology continues to develop, the above specifications are subject to change without notice.
