Technical Specifications
| General Specifications | ||||||
| Frequency Range |
VHF: 136-174MHz UHF: 400-470MHz, 450-520MHz | Number of channels | 48 | |||
| Channel spacing | 12.5/25.0KHz | Operating Voltage | 7.4V | |||
| Standard battery | 2800mah (lithium ion) | Battery average working hours (5-5-90 working cycles) | About 18 hours | |||
| Frequency stability | ±2.5PPM | Operating temperature range | -20℃~+60℃ | |||
| Antenna impedance | 50Ω | Dimensions (H x W x D)(Without antenna) | 110 x 51 x 32mm | |||
| Weight (including antenna and battery) | 225g | |||||
| Transmitter | ||||||
| Output Power | UHF: 9.0W/3.0W, VHF: 9.0W/3.0W | |||||
| Modulation | F3E | |||||
| Clutter and harmonics | -36dBm<1GHz -30dBm>1GHz | |||||
| Signal to noise ratio | 45/40dB | |||||
| Audio distortion | ≤5% | |||||
| Modulation limit | ±2.5@12.5KHz±5.0@25KHz |
|||||
| Audio response(300 ~ 3000HZ) | +1to-3dB | |||||
| Receiver | ||||||
| Sensitivity | ≤0.30/0.20μV | |||||
| Adjacent channel selectivity | 60/70dB | |||||
| Intermodulation | 65dB | |||||
| Spurious response suppression | 70dB | |||||
| Signal to noise ratio | 45/40dB | |||||
| Audio output power | 600mW | |||||
| Audio distortion | ≤5% | |||||
